Landmann 470430 - Pellet Grill Parts and Hardware; Hardware and Small Parts List

PAGE
Pellet Grill
4
AA BB CC EE FF HHGGDD
HARDWARE AND SMALL PART LISTING
Item Qty. Part name
1 1 Chamber
2 1 Lid
3 2 Handle Base
4 1 Lid Handle
5 1 Front Shelf
6 1 Grease Tray
7 1 Bottom Shelf
8 1 Flame Baffle
9 1 Cooking Bracket/right
10 2 Wheel With Lock
11 2 Wheel
12 1 Small Door
13 1 Side Handle
14 2 Leg-B
15 2 Leg-A
Item Qty. Part name
16 1 Lock
17 1 Serving Tray
18 1 Hopper Chute
19 1 Hopper Assembly
20 3 Cooking Grate
21 1 Warming Rack(Small)
22 1 Warming Rack(Large)
23 1 Left Shelf Bracket
24 1 Right Shelf Bracket
25 1 Grease Drain
26 1 Small Hook
27 1 Cooking Bracket/left
28 1 Grease Bucket
29 1 Grill Probe
M6 x 12
29x
M6 x 22
3x
M6
26x
M4 x 10
1x
M4
1x
M6 x 20
4x
M5 x 12
4x
M5 x 12
1x
1x
