Landmann Brooke - Assembly Preparation and Parts; Required Tools for Assembly; Component and Hardware Identification

PAGE 3
When unpacking the Brooke from the carton, make sure you find and become familiar with all the parts listed
below. Use caution as some parts may have sharp edges.
PARTS LIST
HARDWARE LIST
Assembly time: 10 minutes
A Phillips or plain screwdriver and
an adjustable wrench are needed
for assembly.
TOOLS REQUIRED
D
(1) SPARK GUARD HOOP
A
(1) FIREBOX
B
(1) BASE
F
(1) POKER
®
C
(1) SPARK GUARD
(8) M6 x 12MM
BOLT
AA
x 8
(9) M6 FLANGE
HEXNUT
BB
x 9
