MAINTENANCE AND LUBRICATION
TABLE OF CONTENTS
Table 4-2: 900E Series Maintenance Schedule
NORMAL OPERATING SERVICE INTERVALS
ITEM
1st 5 Hours
or 50 Miles
Weeklyor
500 Miles
Monthly or
2,000 Miles
6 Months or
12,000 Miles
Yearly or
25,000 Miles
LUBE
#
NOTES
LIGHTS I I
WIRING & CONNECTIONS I I
FASTENERS I,T I b
KING PIN AND PLATE I C,I,L 6 c
BRAKE AIR SYSTEM I I I
RELAY VALVES I,C
BRAKE ADJ & WEAR I I,T d
SLACK ADJUSTERS I I L 6 c
CAMSHAFT ASSEMBLIES I I L 6 c
HUB OIL I I,L R 8 c
WHEEL BEARINGS I I,T c
TIRE INFLATION & WEAR I I e
WHEEL LUG NUTS I,T I I,T f
SUSPENSION ALIGNMENT I I
AIR RIDE SUSPENSION I,T I,T
FRAME & U/C ROLLERS L c
HYDRAULIC OIL I I R 1 c
HYDRAULIC FILTER R R
HOSES (Inspect & Replace as
needed)
I I I,R
PLASTIC WEAR STRIPS I I C 6 g
ENGINE 9
WARN - 12K PLANETARY
WINCH GEAR CASE
I I 2 c
WARN - 20K & 30K PLANETARY
WINCH GEAR CASE
I I 3 c
DP - 12K, 15K, 20K, & 30K
WINCH GEAR CASE
I I 4 c
BRADEN - 12K & 20K WINCH
GEAR CASE
I I 5 c
WARN - 12K PLANETARY
WINCH CABLE ASSY
I I,L 7 c, h
WARN - 20K & 30K PLANETARY
WINCH CABLE ASSY
I I,L 7 c, h
DP - 12K, 15K, 20K, & 30K
WINCH CABLE ASSY
I
I,L
7 c, h
BRADEN - 12K & 20K WINCH
CABLE ASSY
I I,L 7 c, h
I - Inspect, R - Replace, T - Tighten/Adjust Torque, L - Lubricate, C - Clean
a. Perform at the time shown. Shorten service intervals when operating in severe or dirty conditions.
b.
(SEE PAGE 2-3)for correct torque specifications.
c.
See Table 4-1 for recommended lubricant.
d. See
“Brake System Maintenance” on page 4-16 for procedures.
e. See Serial Number Plate on the front of the semitrailer for proper inflation requirements.
f. See
“Wheel Bearing Lubrication and Adjustment” on page 4-25 for procedure.
g. Plastic wear strips are self lubricating. If chatter or squealing occurs grease wear strip.
h. Inspect prior to and after each use.
