SPECIFICATIONS
This product conforms to the requirements of the following European Regulations, Directives & Rules:-
CE Mark (93/68/EEC), Low Voltage (72/23/EEC), EMC (93/68/EEC),
RoHS (EU2002/95/EC), WEEE (EU2002/96/EC)
In order to reduce environmental damage, at the end of its useful life, this product must not be disposed of along with normal
household waste to landfill sites. It must be taken to an approved recycling centre according to the recommendations of the
WEEE (Waste Electrical and Electronic Equipment) directive applicable in your country.
Supply Voltage ~100V, ~120V, ~220V, ~230V, ~240V 50/60Hz Factory Option
Mains Fuse (~220V>240V = T2A L 250V) (~100>120V = T5A L 250V)
HT Fuse T1A L
Power Consumption 300W
Output Power Rating 100W
Loudspeaker Outputs 1*16 Ohm
1*8 Ohm 2*16 Ohm
1*4 Ohm 2*8 Ohm
Features Pure Class A/B Valve tone
4xEL34B-STR Power Tubes (Matched Set)
4x12AX7 Preamp tubes (Premium ECC83)
Hi & Lo Gain Inputs
Rugged construction
Selectable FX Loop with Level Control (Switchable Sidechain/Insert/Bypass) (Nominal 500mV Level)
Footswitchable Yes, Channel (FS1 Optional)
EQ Passive Bass, Middle and Treble
Resonance Switch
Presence
Switchable Extra Drive Stage
Input Impedance 1MOhm/47pF
Size (H*W*D) 260*675*250
Unit Weight 23Kg
