Model No: 136T, 136TC, 136TNTS
Thermostatic Electric Griddle Commercial & Marine
PARTS LIST October 1, 2008, Rev. F
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
Description
Part
Number
Key
Number
1 K9-XL-722-3 1 PLATE ASY 3’ ACU 136T, 136T-440VM, 136T-480V
K9-XL-724-34 1 PLATE ASSY 3’ ACU W/6.75 136TC-TE
K9-XL-722-W35 1 PLATE ASY 3’ ACU-NO TAPER 136TNTS
2 2N-11030-30 3 ELMNT GRID 208V 1257W ALL
3 2N-11030-29 3 ELE GRD 208/240V4.5KW/6KW 136T
2N-11030-31 3 ELMNT GRID 480V 5991W 136T-480V
2N-11030-48 3 ELE GRD 440V 5991W 136T-440VM
2N-11030-04 3 ELMNT GRID 380V 5991W 136TC-TE-380
4 K9-XL-426 3 ELEMENT PAN PLATE 136T
5 K9-XL-435 3 ELEMENT PAN Z ALL
6 2H-XL-424 3 ELEMENT PAN INSULATION ALL
7 K9-XL-425 3 ELEMENT PAN ALL
8 2C-20201-04 18 WSHR FLT 3/8 USS PLTD ALL
9 2C-20103-06 2 SCRW SM PLT 6 X 3/8 PHL ALL
9 2C-20301-06 18 NUT HEX 5/16-18 PLTD ALL
10 2C-20103-02 18 SCRW SM PLT 10 X .5 PHLSL ALL
11 K9-XL-227 1 SUPPLY WIRE BAFFLE ALL
12 Y9-31200-02-1 1 GROUNDING LUG/+LABEL ALL
13 2C-20202-06 1 WSHR LOCK #10 INT STAR ALL
14 2E-30500-07 1 TRM BLOCK 3PLELRGE 125AMP ALL
15 2C-20103-01 4 SCRW SM PLT 10X7/8 PHIL ALL
16 2E-30500-22 1 TRMINL STRP 8POLE 50A250V 136T
17 K9-XL-507 1 REAR COVER ALL
18 2C-20104-04 3 SCRW PHD ST 8-32X.5 PLTD PHILP ALL
19 2P-70903-08 1 PLG BTN PLTD MTL 5/16 ALL
2P-70903-09 1 PLG BTN PLTD MTL 7/16 ALL
2P-70903-09 4 PLG BTN PLTD MTL 7/16 ALL
20 2A-72500-05 4 LEG 4 W/BOLT DOWN ADJ MARINE
2A-Z0314 4 FOOT, 4” DIE CAST COMMERCIAL
21 2K-70801-02 2 SNAP BUSH 1 3/8 SB1375-16 ALL
22 2T-30402-07 3 STAT ADJ 550o 48 C/T 136T
2T-30402-09 3 STAT ADJ 550° 72 C/T 136TC-TE, 136TC-TE-380
23 2C-20101-77 6 SCRW MS PLT 6-32 X .25 PHD ALL
24 K9-XL-502 1 ELECT. BOX COVER 3’ & 4’ ALL
25 2J-31601-01 3 PILOT LT 250V 6LEAD BLK 136T
2J-31601-02 3 PILOT LT 480V 6LEAD BLK 136T-440VM, 136T-480V/M, 136TC-TE-380
26 Y9-70701-15-1 3 KNOB 550o D PHANTOM 136T
26 Y9-70701-14-1 3 KNOB 550° D PHANTOM 136TC-TE, 136TC-TE-380
27 K9-XL-725-08 1 ELECT BOX ASY 3’ XL\LG 136T
K9-XL-725-081 1 ELECT BOX ASY 3’ XL\LG 136TC-TE
28 K9-XL-422-2 1 ACCESS PANEL ASSY 3’ 136T
29 K9-XL-235-1 1 GREASE BUCKET ASSY S/S 136T
30 K9-XL-228 1 BUCKET SLIDE ASSY 136T
31 K9-XL-504 3 STAT HOLDER 136T
NI K9-50302-15 1 3’ GRAB BAR ASSY 136T-440VM
NI K9-LGCL-234-1 1 DRAWER STOP 136T-440VM
1
1
Qty
Per
To Next Page
