LANPARTE LA3D-S - Battery Instructions; Battery Voltage and Combination Rules

9 Optional Accessories
Standard 1/4 -20
thread hole on bottom
+
+
+ +
+
10 Battery Instructions
Please note that the nominal voltage of the LA3D gimbal is 7.4V.
Each 18350 & 18650 battery is 3.7V. Therefore, the gimbal MUST
operate on a maximum of TWO batteries.
Batteries must be combined as per below scenarios:
Scenario 1: Scenario 2:
Scenario 3:
(with extender tube)
Scenario 4:
(with extender tube)
3.7V + 3.7V = 7.4V
3.7V = 3.7V
3.7V + 3.7V = 7.4V
3.7V+3.7V+3.7V= 11.1V
Handle extension tube
Extending the tube to
install 2pcs 18650 batteries.
11 Battery Extender
Add extension before installing
the optional 2 * 18650 batteries
