SPECIFICATIONS
8
2.1 Machine Specifications
General
Dimensions
2769 mm L x 1702 mm W x 2515 mm H
(109” L x 67” W x 99” H)
Machine Weight
Shipping Weight
385 kg (850 lbs)
499 kg (1100 lbs)
Performance
Speed Application specific
Maximum Load Height 2286 mm (90”) with 76 mm (3”) Overwrap
Maximum Load Weight 1600 kg (3500 lbs)
Capacity
Turntable Dimensions 1651 mm (65”) Diameter
Turntable Rotation Speed 10 rpm (Potentiometer controlled)
Turntable Height 70 mm (2 ¾”)
Turntable Bearing Support 16 Point Suspension – Double Roller Bearings
Turntable Drive
.55 kW (¾ hp) 230 VAC 3 Phase 50/60 Hz TEFC Motor
1750 RPM Motor - 45:1 Speed Reducer
Film Delivery System (FDS)
Lift Speed Potentiometer controlled
Film Stretch System
Roller Brake – Mechanical (Standard)
Electrical (Option)
Lift Drive
.18 kW (1/4 hp) 230 VAC 3 Phase 50/60 Hz
1750 RPM Motor – 100:1 Speed Reducer
Film All Film – includes Hand Film, Pre-Stretch Film
Standard Film Capacity
254 mm (10”) Diameter
508 mm (20”) Length (Standard)
Tension Controls – Mechanical Brake
Tension Release Lever – Off/On
Tension Increase/Decrease – Film Tension Knob
3 – 14 kg (6 – 30 lbs)
Tension Controls – Electric Brake
Tension Increase, Decrease – Film Tension Potentiometer
3 – 14 kg (6 – 30 lbs)
