•Rear Panel
The Rear Panel of the Mini Switch 800 consists of 8x 10/100 N-Way UTP
switch ports, and one DC power connector.
Figure 2-2. The Rear Panel of the 8-Port Switch
- RJ-45 Ports:
8x 10/100N-Way auto-sensing for 10Base-T or 100Base-TX connection.
- Auto MDI/MDI-X:
It can detect the cable straight connect NIC or cascade to a hub or
switch without change the connector, the maximum distance between the
Switch to another device is 100 meters.
- DC Power Connector:
Plug DC Power Adapter’s female end into this device, and the male end
of the DC Power Adapter into a power outlet. The Adapter supply the
Switch with Voltage 7.5V, Current 1000mA.
