User Guide
3.Network Application
This section provides you a few examples of network topology in which the Mini
Switch 800 is used, the Switch is design to be used as a desktop or segment
switch.
The switch automatically learns node address, which are subsequently used to
lter and forward all traf c based on the destination address.
•Stand Alone
The Mini Switch 800 is designed to be a compact desktop size switch,
which is an ideal solution for small workgroup. The Switch can be used as
a standalone switch to which personal computers, server, printer server are
directly connected to form small workgroup.
Figure 3-1. Stand Alone Application
5
