•Enlarge Your Network
You can use Uplink port of the Mini Switch 800 to connect with another
hub or switch to interconnect each of your small switched workgroup to
form a large switched network.
You can connect anyone switch port to hub or switch without crossover
cable by the Auto MDI/MDI-X function.
In the below illustration, two Switches are used to interconnect two small
workgroup. All the devices in this network can communicate with each
other. Connecting servers to the Switch allow other users to access the
server’s data.
Figure 3-2. Example of enlarging your network
6
