5.Technical Specification
This section provides the speci cations of the Mini Switch 800 :
•Speci cation
Standards Compliance IEEE 802.3 10BASE-T Ethernet,
IEEE 802.3u 100BASE-TX Fast Ethernet
ANSI/IEEE standard 802.3 N-Way auto-negotiation
Protocol CSMA/CD
Max Forwarding Rate
and Max Filtering Rate
14,880 pps Ethernet port,
148,800 pps per Fast Ethernet port
LED Indicators Per Port: Link/Activity, Full/Collision
Per Unit: Power
Network Cables 10Base-T:
2-pair UTP Cat. 3, 4, 5 cable (100m),
EIA/TIA-568 100-ohm STP (100m)
100Base-TX:
2-pair UTP Cat. 5 cable (100m),
EIA/TIA-568 100-ohm STP (100m)
Dimensions 165mm x 86mm x 23mm (W x D x H)
Operating Temperature
0ºC to 45ºC (32ºF to 113ºF)
Operating Humidity 10% to 90% (Non-condensing)
External Power Supply DC 7.5V, 1000mA
Power Consumption 4.2 Watt
EMI FCC Class B, CE Mark
8
