6
4. X-OVER
• Full pass x-over switch
When the switch is in the "Full" position, the full range is bypassed.
• Low pass x-over switch
When the switch is in the "LPF" position, frequencies lower than the low pass
frequency setting are passed. The frequency can be adjusted between 50Hz
and 250Hz.
• High pass x-over switch
When the switch is in the "HPF" position, frequencies higher than the high
pass frequency setting are passed.
5. Low pass x-over frequency control
This control is used to select the desired low pass x-over frequency.
The frequency can be adjusted between 50Hz and 250Hz.
6. Bass BOOST
The boost can be selected among 0dB, 6dB and 12dB.
7. REMOTE
Controls the subwoofer amplier gain, from a remote location for ease of
adjustment during listening.
Warning:
Do not connect a level control knob from other manufacturers to the Remote
Sub Level Control of any amplier. Even though the connectors t properly, the
control knob and connector pin positions may be dierent and the amplier
will be damaged.
8. LED
Will illuminate GREEN to indicate the amplier is on and operating normally,
and will be illuminate RED if the amplier shuts down due to short circuit, DC
oset, or overheating detected by on board protection circuitry.
9. Auxiliary outputs
The Auxiliary outputs oer LANZAR ampliers easy, unlimited system expansion.
Route RCA's from the line out of the rst amplier to the line input of a second
amplier when using a single source output.
