English
DISCONNECTING
CONNECTING
10
9
Click
Click
11
11. Disconnect the BuggyBoard™.
At the end of each connector-bolt, slide the
red release buttons down, whilst lifting the
arms up and out of the connectors.
- 8 -
9. Connecting the BuggyBoard™.
Unscrew the fixing screws (81340). Adjust
the width of the arms and click the cotter
pins into the connectors, then tighten the
fixing screws. Ensure that the arms are an
equal distance from the centre of the board
and the cotter pins are locked in the connec-
tors.
10. Leveling the platform.
Unlock the height adjustment screws
(81310) and rotate the platform until level.
Tighten the height adjustment screws.
IMPORTANT !
The BuggyBoard™ must be discon-
nected from the stroller before
folding the stroller.
Do not fold the stroller with the
BuggyBoard™ attached
