Laser BWT15 - Power Interface; HMI

Shenzhen Qilin Laser Application Technology Co., Ltd.
Power Interface
± 15V interface is the interface to provide power for the motor drive inside the control
box, the voltage is plus or minus 15V (± 15V).
* Table below shows the cable interface definition for ±15V.
DC24V interface is the interface to provide power for the control box internal control
system, and the voltage is DC24V (DC24V).
* The table shows the definition of POWER 2 cable connection.
HMI
The HMI port is defined as a 5-pin green terminal through which the mainboard
supplies power and communicates with.
Pin
Signal
Definition
Description
1
V1
power input +15V
+15 external power input, the current of
external power output bigger than 3A
2
GND
GND
Power ground
3
V2
power input -15V
-15 The input power is from the external
power supply, current bigger than 3A
Pin
Signal
Definition
Description
1
24V
Power input
+24V external power input, the current of
external power output bigger than 3A
2
GND
GND
Power ground
Pin
Signal
Definition
Description
1
24V
Output power,500mA
HMI power supply
2
GND
Power ground
3
TXD
HMI sender
Serial port communication TXD signal
4
RXD
HMI receiver
Serial port communication RXD signal
