DIP SWITCH CODING TABLE
TECHNICAL DATA
POWER SUPPLY: ............................................................................................... 12V DC
CURRENT DRAW WITH ALARM ON (989-989EES-988): ..................................... 23 mA
CURRENT DRAW WITH ALARM ON (975-974): ................................................... 16 mA
CURRENT DRAW WITH ALARM OFF (989-989EES-988):..................................... 13 mA
CURRENT DRAW WITH ALARM OFF (975-974): .................................................. 13 mA
EXIT DELAY: ................................................................................................. 40 seconds
MAX. ALARM CYCLE DURATION: ................................................................. 30 seconds
TIME BETWEEN CONSECUTIVE ALARMS ....................................................... 5 seconds
ULTRASONIC SENSOR FREQUENCY: ................................................................. 40 Khz
MAX. BLINKER RELAY CONTACT CAPACITY ...............................................5+5 Ampere
MAX. STOP ENGINE RELAY CONTACTS CAPACITY: ....................................... 8 Ampere
989 range of products meets the requirements of the EEC 95/54 directive
concerning the Electromagnetic Compatibility (EMC) and the EEC 95/56 directive
concerning protection device against unauthorised use of motorvehicle and ETS
norms applied in this case
Dip-switch n° Position Function
1
OFF
ON
AUTO-CODE FUNCTION
DEACTIVATED
AUTO-CODE FUNCTION
ACTIVATED
2
OFF
ON
VOLT DROP SENSING
ACTIVATE
VOLT DROP SENSING
DEACTIVATED
3
OFF
ON
ACOUSTIC TONE
ACTIVATED
ACOUSTIC TONE
DEACTIVATED
4
OFF
ON
CASUAL RE-ARMING AND AUTOMATIC STOP ENGINE
ACTIVATED
CASUAL RE-ARMING AND AUTOMATIC STOP ENGINE
DEACTIVATED
5
OFF
ON
CLOSURE FUNCTION
(COMFORT CLOSING time 1)
CLOSURE FUNCTION
(COMFORT CLOSING ONLY time 25)
6
OFF
ON
ELECTRIC CENTRAL LOCKING
(pulse time 1 sec.)
PNEUMATIC CENTRAL LOCKING
(pulse time 2 sec.)
