13
Information on maintenance and care
Clean all components with a damp cloth and do not use cleaning agents,
scouring agents and solvents. Remove the battery(ies) before storing for
longer periods. Store the device in a clean and dry place.
EU directives and disposal
This device complies with all necessary standards for
the free movement of goods within the EU.
This product is an electric device and must be collected
separately for disposal according to the European
Directive on waste electrical and electronic equipment.
Further safety and supplementary notices at:
http://laserliner.com/info?an=asmalas
Technical data (Subject to technical alterations. 18W32)
Self-levelling range ± 4°
Precision ± 0.4 mm / m
Horizontal / vertical levelling
Automatic with electronic sensors
and servo motors
Self-levelling alignment time
Approx. 50 seconds over the entire
operating angle
Vertical reference beams 90° to rotation plane
Rotation speed 0, 150, 300, 600 rpm
Laser wavelength 635 nm
Laser class 2 / < 1 mW
Power supply Alkali batteries (4x type AA)
Non-rechargeable battery life approx. 12 h
Operating conditions
-10°C ... +40°, max. humidity 80%rH,
no condensation, max. working
altitude 4000 m above sea level
Storage conditions -10°C ... +70°, max. humidity 80%rH
Dimensions (W x H x D) /
Weight (incl. battery)
155 x 130 x 150 mm /
0,75 kg
EN
