LaserLiner AutoSmart-Laser Manual

10
X
Z
Y
A
C
F
G
H
B
E
D
I
J
A
B
C
D
E
F
G
H
I
J
90° outlet, reference/plumb laser
Prism head / laser beam outlet
Operation indicator
Positioning button
(rotate to the left)
Positioning button
(rotate to the right)
Rotary speed for selection,
600 / 300 / 150 / 0 rpm
ON/OFF button
Scan mode
Battery compartment
5/8“ thread
Inserting the batteries
Open the battery compartment and insert batteries
(4 x typ AA) according to the symbols. Be sure to
pay attention to polarity.
The batteries must be replaced if the status
indicator (C) starts to flash.
Axis alignment
Vertical operation
EN

LaserLiner AutoSmart-Laser Specifications

General

Brand	LaserLiner
Model	AutoSmart-Laser
Category	Measuring Instruments
Language	English
