AutoSmart-Laser
09
J
A
C
F
G
H
B
E
D
X
Z
Y
I
A
B
C
D
E
F
G
H
I
J
90° outlet, reference/plumb laser
Prism head / laser beam outlet
Operation indicator
Positioning button
(rotate to the left)
Positioning button
(rotate to the right)
Rotary speed for selection,
600 / 300 / 150 / 0 rpm
ON/OFF button
Scan mode
Battery compartment
5/8" thread
Vertical operation Axis alignment
GB
Manual_AutoSmart-Laser_Rev.0311.indd 09 08.04.11 14:51
