BeamControl-Master BCM
DEUTSCH4
BeamControl-Master BCM
Bedienfeld
1. Integralgriffe
2. Bedienfeld
3. Vertikallibelle Z
4. Batteriefachhebel
5. Gewindeanschluss
6. Rotationskopf
7. Batteriefach
8. Gewindeanschluss
9. Horizontallibelle X
10. Nivellierschraube B
11. Horizontallibelle Y
12. Nivellierschraube C
13. Laserlotstrahl
14. Nivellierschraube A
15. Geschwindigkeit /
Winkelbereich
16. Ein / Aus
17. IR-Empfangsfeld
18. LED´s
19. Handempfänger-Modus
20. Scan-Modus
21. Rotations-Modus
2
3
4
5
1
6
7
8
9
14
10
11
12
13
15
16
17
18
21
20
19
