LaserLiner BeamControl-Master BCM User Manual

BeamControl-Master BCM
ENGLISH14
BeamControl-Master BCM
control panel
1. integral handles
2. control panel
3. vertical Z vial
4. lever for battery
compartment
5. 5/8 in socket
6. rotary head
7. battery compartment
8. threaded connection
9. horizontal X vial
10. levelling screw B
11. horizontal Y vial
12. levelling screw C
13. laser perpendicular beam
14. levelling screw A
15. speed / angular range
16. On/Off
17. IR (infra-red) reception field
18. LEDs
19. hand reveiver mode
20. scan mode
21. rotation mode
2
3
4
5
1
6
7
8
9
14
10
11
12
13
15
16
17
18
21
20
19

LaserLiner BeamControl-Master BCM Specifications

General

Brand	LaserLiner
Model	BeamControl-Master BCM
Category	Measuring Instruments
Language	English
