Cubus / Cubus G
17
E
D
A
B
C
F G
E
H I
A
B
C
D
E
F
G
H
I
Vertical operation
Reference laser outlet
Prism head / laser beam outlet
Infrared signal receptor
Control panel
5/8“ thread
Battery compartment
Connection socket for power
pack/charger.
Power pack/charger
Operation indicator
red: battery is charging
green: charging process complete
Stand and wall bracket
EN
