LaserLiner Cubus User Manual

18
slope
Cubus
1
2
3 4
6
7
5
11
12
9
10
13
1
8
EN
Remote controlControl panel Cubus
1
2
3
4
5
6
7
8
9
10
11
12
13
auto/slope function
auto/slope function LED:
LED off: automatic alignment
LED on: manual alignment
ON/OFF button
Operation indicator
(LowBat: LED flashes)
Tilt function LED
Tilt function
Infrared signal receptor
Infrared signal emitter
Operation indicator
Rotary speed for selection
600 / 330 / 30 / 0 rpm
Scan mode
10° / 45° / 90° / 180°
Positioning button
(rotate to the right)
Positioning button
(rotate to the left)
