21
Technical data
(Subject to technical alterations. 18W10)
Self-levelling range ± 4°
Accurancy ± 0.15 mm / m
Horizontal / vertical levelling
Automatic with electronic sensors
and servo motors
Self-levelling alignment time
Approx. 30 seconds over the entire
operating angle
Vertical reference beams 90° to rotation plane
Rotation speed 0, 30, 330, 600 rpm
Remote control Infrared IR
Laser wavelengths red / green 635 nm / 515 nm
Laser class 2 / < 1 mW (EN60825-1:2014)
Power supply NiMH battery
Rechargeable battery life red / green approx. 14 h / approx. 7 h
Battery recharging time approx. 3 h
Operating conditions
-10°C ... +50°, max. humidity 80%rH,
no condensation, max. working
altitude 4000 m above sea level
-10°C ... +70°, max. humidity 80%rH
Protection class IP 66
Dimensions (W x H x D)
130 x 160 x 145 mm
(with stand and wall bracket)
Weight 1.3 kg (with stand and wall bracket)
Remote control
Power supply 2 x 1.5 V AAA
Remote control range max. 30 m (IR-Control)
Weight (incl. battery) 0.07 kg
EU directives and disposal
This device complies with all necessary standards
for the free movement of goods within the EU.
This product is an electric device and must be collected
separately for disposal according to the European
Directive on waste electrical and electronic equipment.
Further safety and supplementary notices at:
http://laserliner.com/info?an=cubus
EN
