LaserLiner DampCheck User Manual

08
6
DampCheck
1
2
3
4
5
EN
2
ON HOLD OFF
DampCheck DampCheck
1 sec 1 sec
The device switches
off automatically
if left idle for
15 seconds.
Protective covers
Measuring electrodes
LC display
LED wet/dry indicator:
Green = dry
Yellow = moist
Red = wet
ON switch;
Measuring mode/unit of
temperature selection;
Hold function
Battery compartment (rear)
1
2
3
4
5
6
1.
2.
3.
1
Inserting batteries
Open the battery
compartment and
insert batteries
according to the
symbols. Be sure
to pay attention
to polarity.
The „Battery Charge“ symbol (c) appears on the display when
the battery charge is low.
!

LaserLiner DampCheck Specifications

General

Battery type	LR44
Battery voltage	1.5 V
Number of batteries supported	4
Storage temperature (T-T)	-10 - 50 °C
Storage relative humidity (H-H)	0 - 85 %
Built-in display	Yes
Purpose	-
Accuracy	2 %
Temperature measuring range	- °C

Weight and Dimensions

Depth	16 mm
Width	46 mm
Height	85 mm
Weight	49 g
