LaserLiner LaserRange-Master T3 User Manual

LaserRange-Master T3
15
1x 2x
27.1°
1x
27.1°
Important notices
– The laser points to the location that will be measured.
No objects may get into the laser‘s line of measurement.
– The device compensates the measurement for different room
temperatures. Therefore allow the device a brief adaptation period
when changing locations with large temperature differences.
– The device is only conditionally useable in outdoor areas and cannot
be used in strong sunlight.
– The measurement results of outdoor measurements may be influenced
or falsified by rain, fog and snow.
– In unfavourable conditions, e.g. with poorly reflecting surfaces,
the maximum deviation may be greater than 3mm.
– Carpeting, upholstery or curtains will not reflect the laser optimally.
Measure to flat surfaces.
– Measurements made through glass (window panes) can falsify
measurement results.
– An energy-saving function switches the device off automatically.
– Clean with a soft cloth. Water may not be allowed to penetrate
the housing.
Angle function 2:
Angle function 2 1. measurement 2. measurement result
height
The measurement result is determined by the 360° inclination sensor.
The back of the device can be used as a reference surface for
measuring angles.
!
Angle function 1:
angle function 1 measurement
results
The measurement results are determined automatically by the 360°
inclination sensor.
The back of the device can be used as a reference surface for
measuring angles.
!
EN

LaserLiner LaserRange-Master T3 Specifications

General

Type	Line level
Product color	Black
Display type	Digital
Maximum range	30 m
Leveling accuracy (±)	2 mm/m
Distance measuring units	m
Self-leveling range (±)	- °
Accuracy	2 mm
Minimum measurement distance	02.2 m
Battery type	-
Battery included	Yes
