LaserLiner LaserRange-Master T3 User Manual

16
Technical Data (Subject to technical changes without notice. 19W16)
Distance measurement
Precision (typical)* ± 2 mm
Measurement range (inside) ** 0.2 m - 30 m
Angle measurement
Measuring range ± 90°
Resolution 0.1°
Precision 0.1°
Laser class 2 < 1 mW
Laser wavelength 650 nm
Beam divergence < 1.5 mrad
Operating conditions
0°C … 40°C, max. humidity
20 … 85% rH, no condensation,
max. working altitude 2000 m
above sea level
Storage conditions
-20°C … 70°C,
max. humidity 80% rH
Automatic switch-off
Dynamic depending on measuring
mode:
Laser: 30 s - 5 min
Device: 3 min - 8 min
Power supply 2 x 1.5V LR03 (AAA)
Dimensions (W x H x D) 35 x 100 x 23 mm
Weight 82 g (incl. batteries)
* measuring distance up to 10 m with strongly reflective target surface
and at room temperature. The measurement deviation may increase by
± 0.2 mm/m for greater distances and under unfavourable measuring
conditions such as strong sunlight or weakly reflective target surfaces.
** at max. 5000 lux
EN
Err204:
Err208:
Err220:
Err252:
Err253:
Err255:
Err256:
Err261:
Err500:
Error codes:
Calculation error
Internal fault
Replace the battery
Temperature is too high: > 40°C
Temperature is too low: < 0°C
Received signal too weak or measuring time too long
Received signal too strong
Outside the measuring range
Hardware fault

LaserLiner LaserRange-Master T3 Specifications

General

Type	Line level
Product color	Black
Display type	Digital
Maximum range	30 m
Leveling accuracy (±)	2 mm/m
Distance measuring units	m
Self-leveling range (±)	- °
Accuracy	2 mm
Minimum measurement distance	02.2 m
Battery type	-
Battery included	Yes
