LaserLiner RollPilot S6 User Manual

RollPilot S6
09
5
Measurement
To measure from spot to spot
1. Position the pointer (8) on the  rst
marked spot.
2. Move the measuring wheel straight
to the other marked spot.
3. Read off measured value.
EN
EU directives and disposal
This device complies with all necessary standards
for the free movement of goods within the EU.
Further safety and supplementary notices at:
http://laserliner.com/info?an=AEU
Technical data Subject to technical alterations. 20W13
Accuracy ± 0.1%
Range
0 – 9,999.9 m
Measuring wheel radius 79,5 mm
Circumference of measuring wheel 500 mm
Units
m
Dimensions (W x H x D)
190 x 430 x 145 mm (folded) /
245 x 1040 x 100 mm
Weight
1050 g (without accessories)
Manual_RollPilot_S6_Rev20W13.indd 9 01.04.20 13:38
