Activate / deactivate measurement points
Up to two measurement points can be set at one time. They can be assigned
measurement-specic parameters as well as the following properties: maximum
temperature, minimum temperature, manual positioning.
Measurement
Level/Span
Setup
File
Measurement
Type
Add Spot
All added measurement points, lines and areas are removed by selecting „None“.
!
Emissivity
Set Ref
Delete point
The temperature of point 1 (S1)
shows the reference temperature
(R). Refer to Section 10.2.
Set emissivity for point 1 (S1).
Refer to Section 11.1.
The point is deleted.
A * symbol is shown
next to the measured
value if values are de-
fined for measurement
points, lines or areas.
!
The yellow highlight
shows the selection.
Measurement points / parameters
Settings
Emissivity
Set Ref
Delete point
Yes
No
Settings
Emissivity
Set Ref
Delete point
No
Yes
Settings
Emissivity
Set Ref
Delete point
No
No
