1-Shot Distance 2-Shot Missing Line
2-Shot Height 3-Shot Height
TruPulse
®
L2
Values & Key Code
= Horizontal Distance (HD)
= Slope Distance
(
SD
)
= Vertical Distance (VD)
= Height (HT)
= Inclination (INC)
Measured by TruPulse
Calculated by TruPulse
Measurement
Icons
Inclination
Value
Range
Value
