Elementy systemu domofonowego2500
number (the one at which the uniphone responds after its number is selected from
the keyboard).
logical number = physical number + range transposition
Example:
In the facility, apartments with the following numbering shave to be serviced.
Minimum apartment number 310
Maximum apartment number 360
In apartment no. 310 (logical number) we use jumpers to set the physical number
value to 1, in apartment 311 to 2, etc. We set the value of range transposition to
309. Keyboard selection of a number within the range of 310-360 shall cause a
uniphone to ring in that apartment.
Hotel numbering mode
ground floor 001, 002, ... , 010
I floor 101, 102, ... , 110
II floor 201, 202, ... , 210
........................................................
IX-floor 901, 902, ... , 910
In order to attribute numbers fo appartaments to successive numbers wich are set
up in uniphones, is recomended to set up the electronics cassette into hotel numbering.
We use P-2-9-7 program for this purpose and parameter in this program should be
set as 0. Then we have to set range transposition to value wich corresponds to
amount of flats on the floor (there is 10 for example). P-9 program is used for setting
the range transposition and all programs are described in instruction of instalation,
using and programing. Calculation of number wich is set into uniphone in flat number
PXX with hotel numbering mode is calculated according to the following algorithm:
U=P*LL+XX
where:
U- uniphone number
P- floor number
LL- liczba lokali na piêtrze
XX- numer lokalu na piêtrze
For the given example, the numbers at which the uniphones at the apartments have
to be programmed are the following:
001-1 ,002-2, ... , 010-10
101-11 ,102-12,... , 110-20
......................................................
901-91 ,902-92,... , 910-100
