MANUAL FOR USE AND MAINTENANCE
LSC 001 REV. 00 7
STARTING AND SETTING OF THE APPLIANCE
(Range New-Rapid-Spazio-Super 3000-S3EP/EK)
FOLLOW THE INSTRUCTIONS BELOW (WITH REFERENCE TO THE LIST OF COMPONENTS AT
PAGES 24/29.
2.1 STARTING
BOILER FILLING
a) Open the water supply tap mentioned in the pre-arrangement of the system (pict. 1).
b) Check that on the motorpump pressure manometer (17) the water mains pressure is visualized (about
4 bar
).
c) Push the manual filling valve on the equipment (1) until you reach half of the boiler level indicator on the
sight glass (2).
In 1 group models and in the models of the range RAPID/SPAZIO provided with additional steam wand,
to have access to this tap, one needs to remove the drip-tray (9); furthermore, the closing of the tap is manual.
TURNING ON THE MACHINE
a) Turn on the main switch (1 pict-1) mentioned in the pre-arrangement of the system (1-pict 1) then turn
on the switch of the machine (3) moving it to position ON/1 and checking that the electric connection
control-light, where present, turns on.
N.B. According to the water quantity which has been manually filled in, it is possible to operate on
the automatic refill system when you turn on the switch (3) until the boiler water level indicated by
the manufacturer is reached.
ONLY FOR THE EQUIPMENT PRE-ARRANGED TO FUNCTION WITH GAS
a) Open the gas tap mentioned in the pre-arrangement of the system (pict. 1).
b) Turn the gas knob on the machine of 90° degrees (30) until the symbol of the big flame on the knob itself
will be up.
c) Push the knob (30) and the gas lighter (31) at the same time until gas turns on, visible from the inspection
opening (41).
d) Hold the knob (30) and keep it pressed for about 10 seconds and check through the suitable inspection
opening (41) that the flame stays on.
e) It is recommended to turn the gas adjustment knob (30) to the position “small flame” during summer or
hot season to avoid an useless overheating of the coffee cups on the upper grid of the machine (14).
☞
☞
2
