Maintenance
Lastec Mower Specifications, 2961/73AGC
Maintenance Lastec//020515 5-7
5
Engine, 2961/73AGC
Hydraulic Motors Left Hydro-Gear 045959
Hydraulic Motors Right Hydro-Gear 026417
Hydraulic Fluid
1
Lastec Hydro Oil, qt 040642
Hydraulic Fluid Filter 25 Micron, 7 GPM Full-Flow, 3/8” NPT P620
Hydraulic Fluid Capacity 5 quarts
Hydraulic Pump Drive Belt Goodyear BX54 026470
1
Lastec hydraulic fluid is equivalent to Mobile One Synthetic 15W50
Model
1
1
Refer to the Engine Operator’s Manual.
Kawasaki KawasakiFD791D-AS01 046126
Bore & Stroke 75.2mm x 76mm (2.96in x 2.99in)
Total Displacement 675ml (41.19cu in)
Power 29 HP
High / Low Idle Speed 1550/3600 RPM
Compression Ratio 9.0:1
Dry Weight 44.5kg (98.1 lbs) without muffler
Oil API Service Class SC or SH, Visc SAE 10W-30
Oil Capacity 1.6 L (1.7 US qt.)
Oil Filter Cartridge type full flow filter 047663
Fuel Gasoline (unleaded)
Fuel Capacity 12 Gallons
Battery Deka 600U 12V DC, Ratings: CA@32°F=680; CCA@0°F=540 P08638
