Numbers in parenthesis refer to hardware shown on page 3.
Opening the Cover
To open the cover box, cut the bands that hold
the two halves of the box together. Never cut
the top of the box open. Doing this could
easily damage the cover inside. This kind of
damage is not covered under the fabric
warranty. With the bands cut, lift and remove
the top box.
Standing behind the housing looking over the
pool, unroll the cover from left to right.
Unwrap the ropes and run them through the
tracks. There are two methods that can be
used.
Running Ropes in the track
The preferred method of running the rope is
to take a short length of the rope outside of
the track and press it into the track on the
water side.
Hold the rope outside the track to pull the
rope down the length of the track toward the
end of the pool.
Now, feed the rope through the pulley
assembly. Insert the pulley into the end of
the track.
Pull the rope down the back side of the
track toward the cover housing.
Alternate Rope Feeding Method
Another common method of running rope is to
pierce it with a small piece of wire. This wire
then becomes the pulling handle as you feed
the rope into the end of the track. This is
especially useful if encapsulation isn’t being
used and the tracks are already installed.
Install Track in the Encapsulation
Starting at one end, lift the track so it will
interlock with the encapsulation. Make sure
the track extends 1” into the housing.
1
2 3
4
5 6
7
8 9
Step By Step Instructions
© Latham Pool Products, Inc. 2019. All rights reserved.
