Latronics PV Edge Grid Connect - FAULT FINDING

6. Connectthe Active,NeutralandEarthcablesasperdiagrambelow.
7.PushthesocketbackintotheMainBodyuntilitclipsin.
8.ScrewthePressureRingbackintoformatightseal.
9.PlugintoPVEdge.
Todisconnecttheplug,simplypushtheclipinandunplug.
Note: Theclipsectioncanbecompletelytakenoutifalockableconnector
isnotdesired.
N
L
E
Neutral
Active
Earth
Socket
15
FAULTFINDING
HELPFUL HINTS
ShouldtheInverterappeartobemalfunctioningwesuggestthefollowingto
eliminateanyexternalproblems.
TurntheInverterOFFbyswitchingtheDC&external ACCircuit
BreakersOFF.LeaveOFFfor60seconds.
ReconnecttheDCSolarInputbyswitchingDCbreakerON. Alllights
ontheInvertershouldcomeONfor1secondatpowerupandthengo
OFF. The75%lightshouldremainONtoindicatetheSolarInputis
available.SolarInputvoltageneedstobeabovetheautomaticturnON
voltage,seepg18,forthelighttoturnON.Ifthelightdoesnot
illuminatecheckSolarInputforcorrectoperation.
Nextreconnectthe ACgridbyswitchingtheexternal ACbreakerON.
After20secondsthe75%lightshouldbeginflashingtoindicateInverter
reconnectingtothe ACgrid. Thelightwillflashfor60secondswhilethe
PVEdgechecksthatthemainsvoltageandfrequencyarestable.
Shouldthelightnotbeginflashingcheckifthe ACgridispresent.
Afterthe75%lightstopsflashingtheInverterwillbeginfeedingpower
intothe ACGrid.
!
!
!
!
!
!
!
!
MakecertainthatyouunderstandtheoperationoftheInverter.
Rememberthatithasautomaticreconnectiontothe ACgrid.
Makesureleadsandterminalsarenotcorroded,looseorfaultyinany
way.
MakesureCircuitBreakersorswitchesareresetproperly.Ifunsure
switchOFFandONagain.
6
Pushtorelease
