Table 4 Unit IN 550 XT IN 550 XTW IN 590 XTW IN 750 XT
Noise level 60 Hz Â
dB(A) 66 66 66 68
Weight kg 176.5 176.5 279.0 175.5
Distance between device and
environment
‑ Front mm 500 200 200 500
‑ Back mm 500 200 200 500
‑ Right mm 500 200 200 500
‑ Left mm 500 200 200 500
Table 5 Unit IN 950 XTW IN 1590 XTW IN 1850 XTW IN 2560 XTW
ACC area À
°C -50 – 220 -90 – 220 -50 – 220 -60 – 220
Temperature stability Á
K
±0.05 ±0.05 ±0.05 ±0.1
Device dimensions
width x depth x height
mm
560 x 550 x
1325
760 x 650 x
1605
760 x 650 x
1605
1100 x 895 x
1865
Filling volume
‑ minimum L 4.8 10.0 8.0 12.6
‑ Maximum L 17.2 30.6 28.6 34.4
Pump data 50/60 Hz
‑ maximum discharge pres-
sure
bar 3.1 3.1 6.0 6.0
‑ Maximum flow rate l/min 65.0 65.0 120.0 100.0
Connector thread (outer)
inlet/outlet
mm M30 x 1.5 M38 x 1.5 M38 x 1.5 M38 x 1.5
Noise level 50 Hz Â
dB(A) 67 63 62 72
Noise level 60 Hz Â
dB(A) 69 65 62 74
Weight kg 176.0 356.0 287.5 615.0
Distance between device and
environment
‑ Front mm 200 200 200 200
‑ Back mm 200 200 200 200
‑ Right mm 200 200 200 200
‑ Left mm 200 200 200 200
Table 6 Unit IN 2050 PW IN 2560 PW
ACC area À
°C -40 – 140 -40 – 140
Temperature stability Á
K
±0.05 ±0.1
Device dimensions width x depth x height mm 1100 x 895 x 1865 1100 x 895 x 1865
Pressurized devices P
V6 Integral Process Thermostats and High-Temperature Thermostats 165 / 198
