TEXT DISPLAY LCA 042
7
BIN BIN BIN BIN BIN BIN BIN BIN Mess.
1286432168421 number
000 00000 000
000 00001 001
000 00010 002
000 00011 003
000 00100 004
000 00101 005
000 00110 006
000 00111 007
to
110 00110 198
110 00111 199
BCD BCD BCD BCD BCD BCD BCD BCD BCD Mess.
100804020108421 number
000 000000000
000 000001001
000 000010002
000 000011003
000 000100004
000 000101005
000 000110006
000 000111007
to
110 011000198
110 011001199
-THE MESSAGE NUMBER
MESSAGE 000
MESSAGE 001
MESSAGE 002
MESSAGE 003
MESSAGE 199
MESSAGE 000
MESSAGE 001
MESSAGE 002
MESSAGE 003
MESSAGE 199
4.2 THE MESSAGE NUMBER
The message number determines which message text is
invoked. The message number is coded to allow the
maximum quantity of messages to be invoked with the
minimum of message inputs.
Text display LCA 042 offers the of two coding options:
- BIN-coded message numbers, up to 199 pages
- BCD-coded message numbers, up to 199 pages
200 messages are available with the LCA 042. They have
the message numbers 000 ... 199. You can join up to 3
message text lines into one message text. The first line
contains the main information, the other two lines the
additional information.
