5 Technical data
Technical datas for EPC PM 1700; 1900; 2100 Nautic; EPC PM Box Nautic
Computer Specifications
Processor Intel Celeron M 1.3 GHz
Cache / PCI Clock 512MB Level 2 Cache / 400 MHz Bus
System Chipset Intel 82855GME
BIOS Award 2MBit Flash, Supports ACPI
PCI Slot 2x Short length, STD Profile, 32 Bit
Memory Slot 2x DDR-SDRAM (max 2GB)
Graphics Chip Intel 82855GME (Integrated/250 MHz)
IDE Controller 1x IDE Ports, Ultra DMA33/66/100
IDE HDD Automotive 20GB internal, 2.5“ IDE
Parallel Port (LPT) 1x EPP/ECP Port
Ethernet 2x 10/100 Mbps
Serial Ports 3x RS232
USB Ports 4x USB (2.0 compliant, 480 Mbps)
Keyboard Ports 1x PS/2
Mouse Ports 1x PS/2
Audio Ports Line In/Out, Mic In
Remote Controll
Power Specifications
Power Supply Options • 24 VDC ± 15%
• 3A max (Inrush Current ca. 15A)
or
• 110-230 VAC ± 15%
• 1A max (Inrush Current > 30A)
Power Consumtion Operating : 60W (max) (Configuration depending)
or
Operating : 100W (max) (Configuration depending)
General Specifications
External dimensions (W x H x D) EPC PM Box Nautic: 389 x 276 x 114 mm
EPC PM 1700 Nautic: 430 x 390 x 145 mm
EPC PM 1900 Nautic: 483,2 x 444 x 145 mm
EPC PM 2100 Nautic: 534 x 481 x 144 mm
Weight EPC PM Box Nautic: 5,5 kg
EPC PM 1700 Nautic: 10,7 kg
EPC PM 1900 Nautic: 13,0 kg
EPC PM 2100 Nautic: 18,5 kg
Protection type EPC PM Box Nautic: IP 20 all sides
EPC PM 1700/1900/2100 Nautic:
IP 54 Front side; IP 20 Back side
Approvals GL, ABS, DNV, BV, LR, Prepared for IEC 60945
