LAUNCH 440(440W) 455(455W) Installation Manual
22
No
Material code Name
201
201020703 440 Front cross tube assembly
201021126 455 Front cross tube assembly
202 201020697 440 Rear cross tube assembly
201021126 455 Rear cross tube assembly
203
103020132 Screw M8*15 GB/T5789-86
204
201020696
440 Sheave pin assembly
201021132
455 Sheave pin assembly
205 104990120 440 Sheave bearing
202010073 455 Sheave bearing
206 103220066 440 Sheave
104990137 455 Sheave
207 103201514 Air cylinder assembly
208 103100183 L air connector APL6-M5
209 103060358 Pin B6X35 GB882-86
210 103201505 Air cylinder connector
211 103060357 Pin B type 6X20 GB882-86
212 104990117 440 Slack cable roller
104990136 455 Slack cable roller
213 201020707 Slack cable device
214
104990122 Latch bushing
215
103201500 Locking latch
216
103020132 Screw M8*15 GB/T5789-86
217
104990118 Slider
218 103201497 Spring
219 103040138 Flat washer 20 GB/T95-85
220 103201499 Latch pin
