DO NOT touch the iron while storing it.
Risk of burns!
A
Storage
Storage of the board
1. Turn iron and boiler switches to
the off positions. Unplug system. 2.
Take monotube out of cord-holder.
3. Remove cord-holder from iron-
ing board. 4. Place iron in basket.
5. Slide basket under board. 6. Lift
ironing board by both ends, weight
of generator will automatically fold
system. 7. Leave water in genera-
tor until next use. Once boiled,
water does not go stale.
B
C
WARNING
English
9
Technical Data
Steam pressure 40 p.s.i.g / 3.5 bar
Vertical ironing Yes
Boiler capacity 1 quart / 0.9 l
Power supply
USA only 120 V / 60 Hz
220 - 240 V / 50 Hz
Appliance power
USA only max. 1600 W
max. 1800 W
Iron power
USA only 600 W
800 W
Total weight 28 lbs / 12.7 kg
Weight of iron 2.6 lbs / 1.2 kg
Dimensions 51.2 x 15.4 x 7 in.
130 x 39 x 18 cm
Height of the board 31-37 in. / 79-95 cm
