- 17 -
5-2-2 Upper Cover
Open Lever
Hold and lift the Open Leve
to open
the Rear Cover.
5-2-4 Upper Unit
Open Button
How to Open the Upper Unit
Pressing Open Button and lift it to open the
Upper Unit.
How to Close the Upper Unit
1. Lift the Upper Unit a little by left hand.
2. Pull the Lever forward.
3. Fall down the Upper Unit slowly.
Be careful not to pinch your finger when you
close the Upper Unit
In case of jamming, turn the Knob to take out the
jammed note(s) easily.
5-2-5 Guide A
Lift the Guide A to remove jammed notes.
Lever Knob
To Next Page
