Operators Manual
Para obtener una versión gratis de este manual en español, escriba a la dirección
indicada más abajo. Asegúrese de indicar el modelo y el número de serie de su producto.
Pour obtenir gratuitement une version en français de ce manuel, écrivez à l’adresse
ci–dessous. N’oubliez pas d’indiquer les numéros de modèle et de série de votre produit.
Lawn-Boy Inc., Attn.: Parts Dept., 8111 Lyndale Ave S, Bloomington, MN 55420-1196.
Domestic English (EN)
Form No. 3324-469 Rev A
SilverPro Series
Walk Power Lawn Mower
Model No. 10247—200000001 and Up
Model No. 10252—200000001 and Up
Model No. 10323—200000001 and Up
Model No. 10324—200000001 and Up

Questions and Answers

  • T
    Tonya WangAug 5, 2025
    How to fix Lawn-Boy SilverPro 10323 when engine does not start?
    • J
      James KellyAug 5, 2025
      If your Lawn-Boy Lawn Mower engine won't start, try these steps: First, fill the fuel tank with a fresh gasoline-and-oil mixture. Then, move the throttle lever to the Fast position and press the primer three times. Ensure the wire is connected to the spark plug. Finally, clean the spark plug, check the spark plug gap, and replace it if damaged.
  • H
    Heather SanchezAug 9, 2025
    What to do if Lawn-Boy SilverPro 10323 starts hard or loses power?
    • T
      Tiffany BoothAug 9, 2025
      If your Lawn-Boy Lawn Mower engine starts hard or loses power, try the following: Move the throttle to the Fast position. Drain and refill the fuel tank with a fresh gasoline-and-oil mixture. Clean the fuel cap vent hole, and clean or replace the air filter element. Also, clean the lawn mower discharge chute and the underside of the lawn mower deck. Finally, clean the spark plug, check its gap, and replace it if damaged.
  • M
    Matthew LevyAug 13, 2025
    Why is my Lawn-Boy SilverPro 10323 vibrating excessively?
    • C
      Cynthia JensenAug 14, 2025
      If your Lawn-Boy lawn mower or engine vibrates excessively, try the following: Balance the blade and tighten the blade mounting nut. Also, clean the lawn mower discharge chute and the underside of the lawn mower deck. Finally, tighten the engine mounting bolts.
  • T
    Thomas MckinneyAug 18, 2025
    What to do if Lawn-Boy SilverPro 10323 Lawn Mower discharge chute plugs?
    • J
      Jaclyn ReidAug 18, 2025
      If your Lawn-Boy Lawn Mower discharge chute plugs, try these solutions: Move the throttle lever to the Fast position and raise the cutting height. Allow the grass to dry before mowing. Also, clean the underside of the lawn mower deck.
  • T
    Tina DiazAug 22, 2025
    How to fix Lawn-Boy SilverPro 10323 Lawn Mower running rough?
    • B
      Brandi White DVMAug 22, 2025
      If your Lawn-Boy Lawn Mower engine runs rough, make sure the wire is connected to the spark plug. Clean the spark plug, check the spark plug gap, and replace the spark plug if it is damaged. Move the throttle lever to the Fast position. Clean or replace the air filter.
  • P
    Paul WilkersonAug 27, 2025
    Why Lawn-Boy SilverPro 10323 does not self-propel?
    • H
      hmooreAug 27, 2025
      If your Lawn-Boy Lawn Mower isn't self-propelled, check that the end of the cable spring is hooked into the drive bracket. You may need to adjust the self-propel drive cable or clean any debris from under the belt cover.
  • R
    Roy AllenAug 31, 2025
    How to fix uneven cutting pattern on Lawn-Boy SilverPro 10323?
    • M
      Madison BrooksAug 31, 2025
      To correct an uneven cutting pattern with your Lawn-Boy Lawn Mower, ensure all four wheels are at the same height. Sharpen and balance the blade. Change the mowing pattern. Clean the underside of the lawn mower deck.

Summary

Lawn Mower Safety Guidelines

General Lawn Mower Safety

General safety precautions for operating the lawn mower.

Operation

Guidelines for starting, stopping, and general use of the lawn mower.

Pre-Operation Checks and Fuel Mixing

Mixing Gasoline and Oil

Instructions for correctly mixing fuel and oil for the two-cycle engine.

Operating Your Lawn Mower

Starting the Engine

Step-by-step guide on how to start the lawn mower engine.

Stopping the Engine

Procedures for safely shutting down the lawn mower engine.

Maintenance and Servicing

Recommended Maintenance Schedule

A schedule outlining maintenance tasks at different usage intervals.

Servicing the Air Filter

Procedures for cleaning or replacing the air filter element.

Maintaining the Spark Plug

How to clean, inspect, and gap the spark plug for proper engine function.

Blade Maintenance and Care

Inspecting the Blade

How to check the blade for sharpness, wear, and damage.

Sharpening the Blade

Instructions for sharpening the mower blade to maintain cutting performance.

Exhaust Port Cleaning

Storage and Preparation

Mower Troubleshooting Guide

Lawn-Boy SilverPro 10323 Specifications
