Important: Do not o v erfill the crankcase
with oil because the engine may be
dama ged.
Changing and Draining the Oil
1. Star t the engine and let it r un until w ar m. T his
w ar ms the oil so it drains better .
2. P ark the mac hine so that the drain side is
slightly lo w er than the opposite side to assure
the oil drains completely .
3. Diseng ag e the blade control switc h and set the
parking brak e .
4. Stop the engine , remo v e the k ey , and w ait for
all mo ving par ts to stop before lea ving the
operating position.
5. Slide the drain hose o v er the drain v alv e
( Figure 25 ). Place a pan belo w the drain hose .
Figure 25
1. Oil drain valve 2. Oil drain tube
6. R otate oil drain v alv e to allo w oil to drain
( Figure 25 ).
7. W hen oil has drained completely , close the
drain v alv e .
8. R emo v e the drain hose ( Figure 25 ).
Note: Dispose of the used oil at a recycling
center .
9. Chang e the oil filter , if necessar y ( Figure 26 ).
10. Clean around the oil dipstic k and unscrew the
cap ( Figure 24 ).
11. Slo wly pour appro ximately 80% of the
specified oil into the filler tube ( Figure 24 ).
12. Chec k the oil lev el; refer to Chec king the Oil
Lev el in Engine Maintenance , pag e 20 .
13. Slo wly add additional oil to bring it to the full
mark.
Changing the Oil Filter
R e place the oil filter ev er y 100 hours or ev er y
other oil c hang e .
Note: Chang e the oil filter more frequently when
operating conditions are extremely dusty or sandy .
1. Drain the oil from the engine; refer to Changing
and Draining the Oil in Engine Maintenance ,
pag e 20 .
2. R emo v e the old filter using an oil filter wrenc h.
Wipe the filter mounting base surface clean
( Figure 26 ).
3. Apply a thin coat of clean oil to the r ubber
g ask et on the re placement filter ( Figure 26 ).
Figure 26
1. Oil lter wrench 3. Filter base
2. Oil lter 4. Gasket
4. Install the re placement oil filter to the filter
base b y hand. T ur n the oil filter cloc kwise
until the r ubber g ask et contacts the filter base;
then tighten the filter an additional 7/8 tur n
( Figure 26 ). Oil Filter tor que: 15-17 lb (20-24
N ⋅ m)
5. Add the specified amount of the recommended
oil; refer to Changing and Draining the Oil in
Engine Maintenance , pag e 20 .
6. Star t the engine and c hec k the filter for leaks .
7. Stop the engine and c hec k the oil lev el; refer to
Chec king the Oil Lev el in Engine Maintenance ,
pag e 20 . Add oil if necessar y .
