■ A flashing red LED light on the charger indicates that the battery temperature is not within -5 °C– 50 °C
or the charging current is too high.
■ After continuous or repeated charging cycles without interruption, the charger may warm up.
This is normal and does not indicate a technical defect of the battery charger.
BATTERY LED PANEL
■ The panel consists of 4 LEDs on the battery. Press and hold the button, then release it, the LEDs
will show you the charge levels. (Fig. 22)
■ The battery’s charge level can be checked either when the battery is attached on the machine or
removed from the machine.
22
When servicing, use only identical replacement parts. Use of any other parts may create a hazard
or cause product damage.
WARNING
Always wear safety goggles or safety glasses with side shields during power tool operation or when
blowing dust. If operation is dusty, also wear a dust mask.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from
various types of commercial solvents and may be damaged by their use. Use clean cloths to remove
dirt, dust, oil, grease, etc.
WARNING
BATTERY PACK AND CHARGER
MAINTENANCE
Fig. 22
LEDs on battery
(Continuous lighting)
4 LEDs (inc 2 green)
3 LEDs (inc 1 green)
2 LEDs (orange & green)
1 LEDs (red only)
Battery Capacity
Fully charged
Indicator Lights
button
green
orange
red
> 50%
> 25%
< 25%
Recharge required
