Install/Remove the Battery Pack (See Figs. 13-15)
ASSEMBLY
To install the battery pack:
■ Lift the battery compartment cover.
■ Align the support rails located within the battery compartment with the guides in the battery
pack, and then insert the battery pack into the compartment (Fig. 13).
■ Push the battery pack until you hear a “click”.
■ Insert the isolator key into the keyholes located near the battery compartment (Fig. 14).
NOTE: The isolator key only ts into the keyholes in one direction. Do not force it.
■ Close the battery compartment cover.
NOTE: Make sure that battery pack rmly snaps into place and is secured to the mower before
starting operation.
To remove the battery pack:
■ Stop the mower. Lift the battery compartment cover and remove the isolator key.
■ Press the release button on the battery pack, grasp the battery pack rmly and pull out of the
battery compartment (Fig. 15).
■ Close the battery compartment cover.
If any parts are broken or missing, do not attempt to attach the battery pack to the robotic mower
or operate the robotic mower until the broken or missing parts are replaced. Failure to do so could
result in serious injury.
Ensure the isolator key is not tted before installing the battery.
WARNING
