LawnMaster DM15 - OPERATION; Control Panel Overview

20
Control Panel (See Fig. 16)
START/ON
Long press for 3 seconds to power on the mower. Press after selecting the Auto Mow or the
Spot Cutting Button to start mowing.
Battery Indicator
Auto Mow Button
Long press 2 seconds to select random auto cutting mode followed by START/ON.
Error Indicator
Spot Cutting Button
Long press 2 seconds to select spot cutting mode followed by START/ON
.
Ultrasonic Indicator
Ultrasonic On/Off Button
Single press to turn off/turn on the ultrasonic function.
OPERATION
Error Indicator Status
Off The mower is in normal operation.
Yellow, Continuous
The lift sensor is activated. / The obstruction sensor is activated.
/ The mower is tilted. / The rear wheels are lifted (slipping) due
to an obstacle. / The mower has fallen over. / STOP button is
pressed. / The mower cannot see grass.
Red, Continuous Sensor error. / Motor fault. / Operation system error.
4
5
6
Battery Indicator Status
Green, Continuous Sufcient power for mowing/ ready for mowing.
Red, Continuous Recharge required.
Red, Flashing
The temperature of battery pack is abnormal, or the electric
core fault.
2
1
3
Ultrasonic Indicator Status
Green, Continuous The ultrasonic function is on.
Off The ultrasonic function is turned off.
Yellow, Flashing The mower has a communication issue with camera.
7
