LawnMaster FD1501 - Assembling Chassis and Wheels

13
ASSEMBLING THE CHASSIS AND WHEELS
■ Lay the chipper unit on its side.
■ Insert the 2 chassis into the 2 holes on the chipper housing as shown. Make sure the small hole on
the chassis is aligned with the small hole on the chipper housing (Fig. 1).
■ Push the chassis rmly into place and secure with two screws provided using a Phillips screwdriver.
Do not over-tighten the screws (Fig. 1).
WARNING
Do not attempt to modify this product or create accessories not recommended for use with this
product. Any such alteration or modication is misuse and could result in a hazardous condition
leading to possible serious personal injury.
WARNING
Do not connect to power supply until assembly is complete. Failure to comply could result in accidental
starting and possible serious personal injury.
ASSEMBLY
WARNING
Never operate the chipper without the proper safety devices in place and in correct working order.
Never operate the chipper with damaged safety devices. Failure to pay attention to this warning can
result in serious personal injury.
Fig. 1
Small Holes
