14
■ Slide the axle through the 2 holes at the curves of chassis. Slide the two wheels onto the chassis
axle. Place the washers onto the axle. Push straight end of the cotter pins into axle holes and press
into holes until secured (Fig. 2).
■ Align and push the two hub caps into place on both sides (Fig. 2).
ATTACHING THE COLLECTION BAG
Stand the chipper upright and hang the collection bag into the mounting hook as shown (Fig. 3).
Fig. 3
ASSEMBLY
Fig. 2
