KNOW YOUR SCARIFIER/DETHATCHER
The safe use of this product requires an understanding of the information on the product and in
this Operator’s Manual as well as a knowledge of the project you are attempting. Before use of this
product, familiarize yourself with all operating features and safety rules.
Components
1. Start/Stop Bale Switch
2. Upper Handle
3. Cord Retainer
4. Carriage Bolt & Wing Nut
(X4)
5. Middle Handle
6. Lower Handle
10
9
1
2
3
4
5
6
19
17
18
8
20
7. Collection Bag
8. Deck
9. Height Adjustment Lever
10. Rear Wheel
11. Front Wheel
12. Motor Cover
13. Safety Guard Flap
14. Cable Clip (X2)
15. Power Cord
16. Safety Switch Button
17. Dethatcher Cylinder
18. Scarier Cylinder
19. Mounting Bolt
20. Bearing Cover
7
11
12
13
14
15
16
