PARTS AND FEATURES

26CC 2-CYCLE ENGINE PART LIST

Key

Number

Application Description Quantity

1 321001130 Spark Plug Cover 1

2 321001131 Nut 1

3 321001132 Upper Engine Cover 1

4 321001133 Logo 1

5 321001134 $LU'HÀHFWRU 1

6 321002109 Cylinder Air Damper 1

7 321001136 0XIÀHU&RYHU 1

8 321001137 0XIÀHU 1

9 321001138 Insulation Sheet 1

10 321001139 Spark Plug 1

11 321002110 Gasket 1

12 321002111 Ignition Coil Assembly 1

13 321002112 Positive Stop Switch Cable 1

14 321002113 Spacer Set 4

15 321002114 Cylinder 1

16 321002115 Gasket 1

17 321001143 Pawl Assembly 1

18 321002116 Electric Starter Assembly 1

19 321002117 Rear Engine Cover 1

20 321002118 Carburetor Mount Assembly 1

21 321002119 Washer 1

22 321002120 Carburetor 1

23 321001147 Air Filter Base 1

24 321001148 Air Filter 1

25 321001149 Air Filter Cover 1

26 321001150 Rotary Knob 1

27 321001151 Choke Lever 1

28 321001152 Fuel Cap 1

29 321002121 Fuel Tank Grommet 1

30 321002122 Fuel Tank 1

31 321002123 Fuel Tube 1

32 321002124 Fuel Tube 1

33 321002125 Fuel Line Filter 1

34 321001154 Rubber Pad 1
