SPECIFICATIONS
TORQUE SPECIFICATIONS
Engine Size 2-Stroke / Full Crank
Engine Displacement 26cc
Ignition Capacitor Discharge Ignition (CDI)
Carburetor All Position Diaphragm Type With Primer Bulb
Air Filter Foam (Dry)
Engine Shut Off Auto-Reset
Throttle Control Variable Speed Trigger
Fuel / Oil Ratio 40 : 1
Fuel Tank Capacity 400 ml
Spark Plug Champion RCJ6Y
Rotor Air Gap 0.012”-0.015” (0.30-0.40 mm)
Spark Plug Gap 0.026” (0.65 mm)
Run Time on Full Tank 40 Minutes
UNIT SPECIFICATIONS
Engine
Fuel System
General
Application Description
Torque Torque
(IN.LBS) (N.m)
Crankcase
Tighten the screws securing the front and back
sections of the crankcase.
53-62 6-7
Cylinder to crankcase Tighten the screws securing the cylinder to crankcase. 53-62 6-7
Flywheel to crankshaft
3UHVFUHZWKHÀDQJHKH[DJRQQXW0DQGWKHQ
tighten.
89-133 10-15
Spark plug to cylinder
Pre-screw the spark plug to cylinder, and then tighten
with pneumatic screwdriver.
115-137 13-15.5
&OXWFKWRÀ\ZKHHO 7LJKWHQWKHEROWVVHFXULQJWKHFOXWFKWRÀ\ZKHHO 71-89 8-10
Ignition coil to cylinder
Tighten the screws securing the ignition coil to
cylinder.
27-35 3-4
